Tensile: 1570 mpa to 2160 mpa.
packing on plystic, wooden or plywood reels 25m to 2000m.
Delivery: 30 days for a 20 feet container(24.5 tons).
| Reference | Construction |
| Steel strand | 1×7, 1×19, 1x19S, 1*19W, 1*25Fi, 1*29Fi |
| Aircraft cable | 7×7, 7×19 |
| Traw fishing application | 6x19AW+FC, 6x19AS+FC 6×19+FC, 6X19+IWRC 6×37+FC, 6X37+IWRC 6*7+FC, 7*7, 6*24+7FC |
| Hoisting lifting applilcation | 7×7, 7*19, 6*19W+IWS 6*19+FC, 6X19+IWRC 6×37+FC, 6X37+IWRC 6*19S+FC, 6x19S+IWRC 6*19W+FC, 6*19W+IWRC 6*25FI+FC, 6*25FI+IWRC 6*29FI+FC, 6*29FI+IWRC 6*31WS+FC, 6*31WS+IWRC 6x36WS+FC, 6*36WS+IWRC |
| Combination rope for fishing | 3(1×19), 3(1×24), 6(1×19), 6(1×24), 6(1×7), etc. OEM |
| Non-rotating Steel wire rope | 18×7+FC, 18×7+IWS, 19×7 |
| Winch lifting application | 4X25Fi+PP, 4X26WS+PP, 4X31S+PP, 5X26WS+PP 6*19W+IWS, 6*19W+IWRC |
Steel wire rope constructions & diameters
| Surface | Construction | Diameter (mm) | Tensile Strength |
| Ungalvanized, | 1×7 | 0.6–14 | 1270N/mm2–1960N/mm2 |
| Electric galvanized, | 1×19 | 1.0–8.0 | |
| Hot dipped galvanized, | 1×12 | 1.0–8.0 | |
| PVC/PE/NYLON, | 7×7 (6×7+IWRC) | 1.0–20 | |
| Stainless steel AISI304/316 | 6×19+IWRC | 3.0–56 | |
| 6x19W/S+IWRC | 6.0–38 | ||
| 6×37+IWRC | 6.0–64 | ||
| 6×19/25Fi+IWRC | 6.0–44 | ||
| 8x19S/W+IWRC | 8.0–16 | ||
| 8x19S+IWRC | 8.0–16 | ||
| 6x36WS+IWRC | 8.0–56 | ||
| 19×7 | 4.0–28 | ||
| 6×19+FC | 3.0–56 | ||
| 6x19W/S+FC | 6.0–36 | ||
| 6×37+FC | 6.0–64 | ||
| 6x19Fi+FC | 6.0–44 | ||
| 8x19S/W+FC | 8.0–16 | ||
| 8x19S+FC | 6.0–16 | ||
| 6x36WS+FC | 8.0–56 | ||
| 6×24+7FC | 6.0–56 | ||
| 6×12+7FC | 3.0–32 | ||
| 18×7+FC | 4.0–28 |
Outline and function of wire rope surface grease
Almost all wire ropes work in very harsh environment: wet environment, sun exposure, strong acid environment, strong rust and wear seriously affect the service life. In the process of production and use, the wire rope should be regularly oiled in order to strengthen the anti-corrosion performance of the wire rope and increase the mechanical lubrication coefficient of the wire rope and machinery equipment to reduce the wear of the wire rope.
Classification of wire rope
According to the section shape of wire rope: round wire rope and special-shaped wire rope.
Classification of galvanized steel wire rope
Galvanized wire rope is divided into two types: cold galvanized wire rope and hot galvanized wire rope.Hot dip galvanizing and cold dip galvanizing have this essential difference on the craft hot dip galvanizing is to rely on physical heat diffusion action to form coating, form iron and zinc compound first, form pure zinc layer successively on the surface of iron and zinc compound.
Steel wire rope, also known as wire cable or steel cable, is a versatile and durable type of rope made from multiple strands of steel wire twisted together. It is widely used in various industries for lifting, hoisting, towing, and other applications that require strong and reliable tensile strength.
Key Features of Steel Wire Rope:
Strength and Durability: Steel wire rope is known for its exceptional strength, allowing it to withstand heavy loads and provide reliable lifting capabilities. It is highly durable, with excellent resistance to abrasion, corrosion, and fatigue.
Construction: Steel wire rope is typically constructed with several individual strands twisted around a central core. The number of strands and the arrangement of wires within each strand can vary depending on the desired strength and flexibility of the rope.
Wire Types and Coatings: The steel wires used in wire rope can be made from various grades of steel, such as carbon steel or stainless steel, each with its own properties and applications. Additionally, steel wire rope can be coated with materials like zinc, galvanized, or stainless steel coatings to enhance corrosion resistance.
Flexibility and Bendability: Despite its strength, steel wire rope retains a certain level of flexibility, allowing it to conform to various shapes and bend around sheaves or pulleys. Different configurations, such as braided or non-rotating designs, are available to suit specific applications.
Versatility: Steel wire rope finds applications across numerous industries, including construction, mining, marine, transportation, oil and gas, and agriculture. It is used for tasks such as lifting heavy loads, supporting structures, mooring ships, suspending overhead cranes, and more.
Safety Considerations: Proper training, handling, and maintenance are essential when working with steel wire rope to ensure safe operations. Regular inspections, lubrication, and replacing worn or damaged sections are crucial for maintaining the rope’s integrity.
Steel wire rope is available in various diameters, strengths, and configurations to suit different applications. It offers a reliable and robust solution for demanding tasks that require high tensile strength, durability, and resistance to environmental conditions. When selecting steel wire rope, it is important to consider factors such as load capacity, working environment, and specific industry regulations to ensure optimal performance and safety.
